BOB57 O4 Cinematic 6S HD

In the Box

• BOB57 O4 BNF

  x 1

• Battery pads

  x 1

• GemFan 6032 Prop(Pairs)

  x 2

• 5.8G SMA Antenna

  x 2

• Battery strap

  x 2

• GemFan 6032 Prop(Pairs)

  x 2

Description

The iFlight BOB57 is a long-range HD drone that was designed in collaboration with pilot & videographer Ellis van Jason. The team crafted this cinematic 6-inch drone that ensures agility and flight time while combining the advantages of both 5-inch and 7-inch drones for both cinematic and freestyle flights.

Highlights

Hybrid motor design optimized for that can be used with both bi-blade and tri-blade 6″ propellers

High-end GPS is used to minimize the risk of failure during proximity flights

Long backbone with enough space up to fit 3000mAh 6S batteries

Solid antenna mount for less ocillations when using long antennas

Gladiator shell protects from dust and water droplets

ESCs with built-in spike absorber for more reliability

Built in BEC to directly power a GoPro camera

9-minute flight time with 3000mAh 6S Lipo

Front-mounting XT-60

Specificaitons

Product Name: BOB57 O4 6S HD BNF

FC: BLITZ F722

ESC: BLITZ E55 55A 4-IN-1 ESC

Video Transmission: DJI O4 Air Unit Pro

Frame: 280mm wheelbase

Motor: XING2 2506 1500KV motors

Prop: GEMFAN 6032-3 propellers

Weight: 570±5g

Takeoff Weight: Approx.795±5g (With 6S 1480mAh)

Dimensions (L×W×H): 226×166×34 mm

Max Speed: 180 km/h (Manual Mode)

Maximum Takeoff Altitude: 7000 m

Max Hover Time: Approx. 8.5 mins (With 6S 1400 no load.)

Max Wind Speed Resistance: Level 7

Operating Temperature Range: -10° to 40° C

Antennas: 2 Antenna

GNSS: GPS+SBAS+Galileo+QZSS+Glonass

Video Transmission

Product Name: DJI O4 Air Unit Pro

Image Sensor: 1/1.3-inch

Lens: FOV: 155°

ISO: 100-25600

Video Resolution: 1080p/100fps H.265

Video Format: MP4. Max Video Bitrate: 130Mbps

Color Mode: Normal Mode/D-Log M

Stabilization: RockSteady 3.0+ ; Stabilization function off (When RockSteady is enabled. the shooting angle only supports standard.)

Live View Quality: 1080P@100fps

Operating Frequency: 5.170-5.250 GHz & 5.725-5.850 GHz

Transmitter Power (EIRP): 5.1GHz＜23dBm(CE)/5.8GHz＜33dBm(FCC)/＜14dBm(CE)/＜30dBm(SRRC))

Max Video Transmission Range: With DJI Goggles 3/DJI Goggles N3: 15 km (FCC). 8 km (CE). 8 km (SRRC)

Communication Bandwidth: Max 60 MHz

Antenna: Dual antennas

Built-in Storage: 4GB

Supported SD cards: microSD (up to 512GB)

Operating Temperature: -10° to 40° C

Weight: Air Unit (camera module included): Approx. 32 g

Dimensions: Transmission Module: 33.5×33.5×13 mm (L×W×H)

Packing List

1 x BOB57 6S O4 HD BNF

2 x Antennas

1 x Battery pads

2 x Prop(Pairs)

Note

1. iFlight products may be used for civilian purposes only and any direct or indirect use of iFlight products for or in connection with the following is prohibited:

(1) Any military combat purpose or military combat related use;

(2) Terrorist activities: The purchaser also shall require its customers or end users to comply with the foregoing requirements.

2. iFlight Partners must strictly adhere to applicable export control and sanction laws as well as any written compliance requirements regarding these controls issued by iFlight from time to time.

If Party A has violated applicable export control or economic sanctions laws and regulations. Party B has the right to immediately suspend delivery of products to Party A or terminate relevant cooperation without any liability.

For more specific content. please check: https://shop.iflight.com/Export-Policy-info
