CONQUER NEW MOUNTAINS
MORE DYNAMICS AND RANGE WITH LESS WEIGHT
Shimano’s EP8 electric drive is not only dynamic and strong. but also offers a light system weight that perfectly supports the agile geometry of the JAM² 7.8. Our specially developed. integrated but removable battery with 720 Wh also supports you on your long rides. You can also charge your devices via a USB-C charging port on the top tube.
OPTIMIZED KINEMATICS
With the further development of our well-known FOLD kinematics. you can now make it even harder with your JAM² 7.8. We retained the popular sensitivity of the FOLD. but changed the positioning of the kinematics in the frame to provide better resistance to punctures. The characteristic curve is completely progressive and ensures a super stable chassis on tough terrain. E-MTBs in particular. with their additional weight due to the motor and battery. benefit from the greater progression. This feature allows you to master any trail while the chassis still provides you with enough comfort for long trail rides. Additionally. a lower standover height provides more freedom to play with your JAM² 7.8 on the trail.
MORE FUN ON THE TRAILS
The driving characteristics are our top priority. With the JAM² 7.8. every ride will be more fun. An agile. maneuverable geometry with a slim. compact design lets you fly over all trails. whether technical or flowing. With the FLIP CHIP on the linkage of your JAM² 7.8 you can adapt your geometry to an even more aggressive riding style. The small adjustment of the head angle from 65.5° to 65° changes your set-up to even more downhill potential. In addition. the specially developed CIS design ensures a tidy look in the cockpit and always ensures perfect shifting and braking. All cables run on the handlebars into the stem and through the headset into the frame. In addition. all of your essential parts fit in the accessory pocket between the top and down tubes.
STRONG AND DYNAMIC SHIMANO EP8 E-DRIVE WITH INTEGRATED. REMOVABLE 720 WH BATTERY
150 MM SPRING TRAVEL WITH NEW FOLD KINEMATICS OPTIMIZED FOR MORE PROGRESSION
LONG SERVICE LIFE AND RELIABLE SHIFTING: SHIMANO SLX GROUP AND 4-PISTON BRAKE. AS WELL AS FULLY INTEGRATED CIS CABLE ROUTING FOR A CLEAN LOOK WITH TOP PERFORMANCE
This bike arrives (almost) fully assembled. All you have to do is straighten the handlebars and attach the pedals.
| Frame | 7005 hydroformed aluminum. 3D forging. 150 mm FOLD GEN2 kinematic. 148×12 mm thru axle. internal cable routing. USB-C port. post mount 203 mm |
| Frame shape | Mountain bike |
| material | aluminum |
| Gender | Unisex |
| Weight | approx. 25.0 kg |
| maximum weight allowed | 150kg |
| Fork | Rock Shox 35 Gold RL 29 Boost * or DVO Diamond E3 *. 110×15 mm. 44 mm rake |
| mute | Rock Shox Deluxe Select. 210/55 mm. hardware: 25.0 x 8.0 mm. no bushing |
| Manufacturer switching group | Shimano |
| Rear derailleur | Shimano SLX M7100. 12-speed |
| Number of gears | 1×12 |
| Circuit type | Derailleur gears |
| crank | Samox EC40 ISIS |
| cassette | Shimano Deore CS-M6100. 12-speed |
| Drive type | Chain drive |
| Freewheel/resignation | Freewheel |
| Pedals included | no |
| rims | RaceFace AR30 offset |
| Hubs | front: Shimano MT410. 15×110 mm. rear: Shimano MT410. 12×148 mm |
| Wheel size | 29 inches |
| tires | MAXXIS MINION DHF. 63-622 |
| Manufacturer engine | Shimano |
| engine | Shimano Steps EP8 |
| Max. Torque | 85 Nm |
| Range | up to 150 km |
| Support | up to 25 km/h |
| battery pack | 720 Wh |
| display | Shimano SC-E5003 |
| Brakes | Shimano MT520. hydraulic disc brake |
| Handlebars | Handlebar. 800 mm. rise: 35 mm. backsweep: 9° |
| Seat post | Post Modern dropper post PM-214. 34.9 mm |
| saddle | Focus Race SL |
| Stem | FOCUS CIS integrated. 50 mm. 0°. 35 mm. aluminum |
| Accessories/Other | Charger included |
| color | Black, Green |
|---|---|
| Size | L, M, S, XL |
