ProTek60 Pro O3 6S HD Cinelifter

In the Box

• ProTek60 Pro O3

  x 1

• Nazgul 6x4x3 Propellers

  x 4

• Fullsend X 6S 5600mAh Battery

  x 1

• Battery Quick Release Mount

  x 1

• Camera Lens Sponge

  x 1

• EVA Sponge

  x 1

• Prop Wrench

  x 1

• XT90 Male to XT60 Female Adapter Wire

  x 1

• Battery Strap

  x 2

Description

We’ve come a long way with action cameras. offering outstanding quality with little weight and a small footprint. But do you want to get professional or shoot some commercials. maybe get into cinema videography? Well. then you need to step up your game. Those cameras offer higher quality but bigger lenses. higher weight in exchange for all the dynamic range. color profiles. and crisp footage you might possibly want.

The latest version of this drone is the ProTek60 Pro O3. It has been updated to support the DJI O3 Air Unit.

Highlights

Protected Propellers for indoor and outdoor use. protecting whatever you might bump into from nasty cuts

DJI O3 HD Air Unit Low-Latency Digital Transmission with 4K Stabilized Video with 155° Ultra-Wide Angle

Universal camera mount and accessories for a wide range of cameras to install

Updated BLITZ E80 4-IN-1 ESC for more power and reliability

Big size XING2 3110 power motors with extreme lift and flight performance

BLITZ M10 GPS module pre-installed (BF GPS rescue or INAV GPS RTH feature available)

Camera Power Supply Module // IFlight Camera Power 12V 3A BEC Module Short-circuit Protection Function

Changelog

June 12. 2023 : The standard battery is changed to Fullsend X 5600mAh 95C battery.

May 8. 2024 : The Albatross antenna is available in two versions. and will be shipped randomly.

Specification

Product Name: ProTek60 Pro O3

FC: BLITZ F7 Pro Flight Controller

ESC: BLITZ E80 4-IN-1 Pro ESC

Video Transmission: DJI O3 Air Unit

Frame: 282mm wheelbase

Motor: XING2 3110 1600KV motors

Prop: Nazgul 6x4x3 propellers

Weight: 1466g

Max Speed: 110 km/h (Manual Mode)

Maximum Takeoff Altitude: 3200 m

Max Hover Time: Approx. 5.5 mins with 1.3KG load and 6S 4500mAh battery

Max Wind Speed Resistance: Level 6

Operating Temperature Range: -10° to 40° C (14° to 104° F)

Antennas: Dual Antennas

GNSS: GPS+SBAS+Galileo+QZSS+Glonass

Video Transmission

Product Name: DJI O3 Air Unit

Weight: Approx. 36.4 g（headband included）

Communication Bandwidth: Max 40 MHz

FOV (single screen): 155°

Communication Frequency: 2.400-2.4835 GHz (RX only) / 5.725-5.850 GHz (RX and TX)

End-to-End Latency

With DJI FPV Goggles V2:

810p/120fps Video Transmission Quality: The latency is lower than 28 ms.

810p/60fps Video Transmission Quality: The latency is lower than 40 ms.

With DJI Goggles 2:

1080p/100fps Video Transmission Quality: The latency is as low as 30 ms.

1080p/60fps Video Transmission Quality: The latency is as low as 40 ms.

Max Video Transmission Bitrate: 50 Mbps

Max Video Transmission Range：10 km (FCC). 2 km (CE). 6 km (SRRC)

Operating Temperature Range: -10º to 40º C (14° to 104° F)

Power Input: 7.4-26.4 V

Audio Transmission: N/A

Packing List

1 x ProTek60 Pro O3 BNF

1 x Nazgul 6x4x3 Propellers(Pairs)

2 x Albatross LHCP 5.8GHz SMA FPV Antenna

1 x XT90 Male to XT60 Female Adapter Wire

1 x Fullsend X 6S 5600mAh Battery

2 x Battery Strap

1 x XT90 Smart Smoke Stopper

1 x Prop Wrench

Important

Don’t worry about tuning. we did that for you already! A basic PID- and Filter tuning was applied for a great flight experience!

To restore lost tunes or updates. please check our linked article on “Firmware/Factory Dumps”

Angle-Mode (self balancing level mode) is enabled by default to make sure your first flight doesn’t end in a mess!

Please check our linked article on “How to disable Angle-Mode. activate Acro-Mode”

Note

1. iFlight products may be used for civilian purposes only and any direct or indirect use of iFlight products for or in connection with the following is prohibited:

(1) Any military combat purpose or military combat related use;

(2) Terrorist activities: The purchaser also shall require its customers or end users to comply with the foregoing requirements.

2. iFlight Partners must strictly adhere to applicable export control and sanction laws as well as any written compliance requirements regarding these controls issued by iFlight from time to time.

If Party A has violated applicable export control or economic sanctions laws and regulations. Party B has the right to immediately suspend delivery of products to Party A or terminate relevant cooperation without any liability.

For more specific content. please check: https://shop.iflight.com/Export-Policy-info
