SH CineLR 7 WTFPV

In the Box

• Antennas

  x 2

• SH CineLR 7 WTFPV

  x 1

• Battery Strap

  x 2

• HQ 7.5X3X3 Propeller(Pairs)

  x 2

Compatibility

This product does not include a camera and video transmission (VTX) system. Customers must install these components separately.

Compatible with:

DJI O4 Air Unit Pro HD system

DJI O3 Air Unit HD system

BLITZ 1.6W VTX

BLITZ Whoop 1.6W VTX

BLITZ Mini Force 600mW VTX

Description

iFlight’s new generation FPV drone. the 7-inch long-range CineLR 7. combines sleek design. easy maintenance. and a high-performance electronics system. The WTFPV version is compatible with various video systems. offering you a range of options. Whether you’re tackling freestyle tricks. high-speed pursuits. or long-range filming. CineLR 7 is engineered to meet diverse flying needs with precision and reliability.

Features

Innovative Frame Design. No Props in View

SH Series adopted an innovative frame design with no props in view while allowing flexibility for freestyle tricks. With balanced motor output. provides enhanced overall flight performance.

Quick-release Side Panels

Quick-release side panels provide protection against debris and allow for easy maintenance while ensuring a cleaner setup with no cable entanglement.

Up to 25mins Long-range Flight Time

Capable of carrying an efficient high capacity battery. explore the skies like never before with extended flight time. Recommended 6S 4000mAh Li-Ion above (slow cruising) or 6S 3300mAh lipo battery.

High-performance Core Electronics System

Equipped with racing-grade BLITZ F7 FC and BLITZ E55 4-IN-1 ESC for high-intensity flight maneuvers. It features a larger MOS and offers a 65A max burst current. which enhances stability and improves heat dissipation.

Built-in high-precision GPS Module

The integrated high-precision GPS module with tpu cover prevents signal loss from external damage. reducing flyaway risks and enhancing device safety.

Specificaitons

Product Name: SH CineLR 7 6S WTFPV

Geometry: H-shaped

FC: BLITZ F7 Flight Controller

ESC: BLITZ E55 4-IN-1 2-6S 55A ESC

Video Transmission and Camera: None

Frame: 334mm wheelbase

Motor: XING2 2809 1250KV motors

Prop: HQ 7.5X3X3 propellers

Weight: 741±5g(Without Battery)

Takeoff Weight: Approx. 1599±5g (incl. 21700 6S 8000mAH)

Dimensions (L×W×H): 285*196*45mm

Max Speed: 140km/h

Maximum Takeoff Altitude: 7000 m

Max Hover Time: Approx. 18mins with 6S 3300mAh battery No Load

Approx. 25mins with 6S 8000mAh battery No Load

Recommended load: 800g

Max Wind Speed Resistance: Level 7

Operating Temperature Range: -20° to 40° C

Antennas: Dual Antennas

GNSS: GPS+SBAS+Galileo+QZSS+Glonass

Packing List

1 x SH CineLR 7 6S WTFPV

1 x Battery pad

2 x 7.5 inch Prop(Pairs)

2 x Battery strap

1 x Screw bag

1 x Cable set
