The Viper PST Gen II hands an unfair advantage to shooters who seek to keep the upper hand in every situation from close quarters to long-range shots. The illumination dial is cleanly integrated into the side focus adjustment knob for easy access and streamlined performance. The glass-etched reticle offers shooters highly functional. intuitive. and detailed hold points. yet remains uncluttered for optimal viewing and features 10 intensity levels with off positions between each setting.
Viper PST Gen II 5-25×50 FFP Dimensions (in inches)
| Lengths | |||||
|---|---|---|---|---|---|
| L1 | L2 | L3 | L4 | L5 | L6 |
| 15.79 | 2.37 | 2.58 | 6.59 | 5.6 | 3.59 |
| Heights | |
|---|---|
| H1 | H2 |
| 2.3 | 1.8 |
| Magnification | 5-25x |
|---|---|
| Objective Lens Diameter | 50 mm |
| Reticle | EBR-7C (MOA) |
| Turret Style | Tactical |
| Tube Size | 30 mm |
| Adjustment Graduation | 1/4 MOA |
| Parallax Setting | 25 yards to infinity |
| Max Windage Adjustment | 35 MOA |
| Max Elevation Adjustment | 70 MOA |
| Travel Per Rotation | 25 MOA |
| Field of View | 24.1-4.8 ft/100 yds |
| Eye Relief | 3.4 inches |
| Length | 15.79 inches |
| Weight | 31.2 oz |
EBR-7C (MOA)
Hash-marked reticle using MOA or MRAD-based subtension lines and floating wind hold dots for ranging. holdover. and windage corrections. Letters refer to reticle subtensions listed in chart below.
Subtension detail for Viper PST Gen II 5-25×50 FFP riflescope with EBR-7C MOA reticle.
INCLUDED IN THE BOX
- CR2032 battery
- Lens cloth
- 2 mm hex wrench
- 3″ sunshade
| Size | EBR-7C (MOA), EBR-7C (MRAD) |
|---|
